PRE-CRUSH COMPACTORS

Ace Equipment Company Pre-Crush Compactors are used to demolish waste products before being compacted into a container. They do this by compacting the waste into a wall that will then raise up and allow the material to be compacted into the container. These machines are commonly used to prevent resale of products, along with products that will not be compacted well into a container regularly.

Ace Equipment Pre-Crushers come in 2, 4 and 6-yard chamber sizes. All are BUILT TUFF / BUILT RIGHT and ready for whatever you throw at them.

Perfect for:

Automotive Manufacturers
Equipment Manufacturers
Distribution Centers
Appliance Manufacturers
Transfer Stations
Product Destruction

REQUEST A QUOTE

DOWNLOAD BROCHURE

FEATURES

4” Thick Solid Steel Front Wall
No Limit Switches
Slot & Tab Construction
Constructed with Hardox® Steel
Tongue & Groove Floor & Sidewalls
PLC Driven for Improved Productivity
Largest Charge Chamber in the Industry
Available with Optional AR500 Liners
American-Made Hydraulic Cylinders
American-Made Electric Motors

BENEFITS

Tongue & groove floor and sidewall construction prevents debris from getting underneath the floor or sides for smoother operation and longer life
Customizable Loading Chutes Can Be
Installed to Sllow for Automated Loading
of Large Bulk Items to Ensure Both
Safety and Productivity
Designed to Dramatically Reduce the Volume
of Materials Prior to Being Compacted, thus
Increasing the Payload of Compacted Materials
and Delivering Exceptional ROI

DIMENSIONS AND SPECIFICATIONS

DIMENSIONS	A2-PC	A4-PC	A5-PC	A6-PC
A	160″	201″	245″	262″
B	79-1/2″	79-1/2″	79-1/2″	79-1/2″
C	101-1/2″	101-1/2″	101-1/2″	101-1/2″
D	51-1/4″	51-1/4″	51-1/4″	51-1/4″
E	60″	60″	60″	60″
F	32″	32″	32″	32″
G	15-1/2″	15-1/2″	15-1/2″	15-1/2″

SPECS	A2-PC	A4-PC	A5-PC	A6-PC
Clear Top	48″ x 60″	60″ x 60″	88″ x 60″	102″ x 60″
Capacity	2 cubic yard	4 cubic yard	5 cubic yard	6 cubic yard
Ram Face Size
Weight	17,000 lbs.	19,000 lbs.	20,000 lbs.	22,000 lbs.

Cycle Time	67 sec	58 sec	49 sec	53 sec
Total Normal Face	84,731 lbs.	84,731 lbs.	84,731 lbs.	84,731 lbs.
Normal Ram Face Pressure	51.9 psi	51.9 psi	51.9 psi	51.9 psi
Ram Penetration	15″	13″	11″	11″

Electric Motor	15hp	20hp	30hp	30hp
Control Voltage	120 vac	120 vac	120 vac	120 vac
Standard Controls	Auto start with manual controls

Pump Capacity	16 gpm	22 gpm	33 gpm	33 gpm
Normal Pressure	2,200 psi	2,200 psi	2,200 psi	2,200 psi

Cylinders	1	1	1	1
Bore	7″	7″	7″	7″
Rod	5″	5″	5″	5″
Stroke	72″	86″	107″	116″

Face Plate	1/2″	1/2″	1/2″	3/4″
Platen Sides	1/2″	1/2″	1/2″	1/2″
Platen Bottom	1/2″	1/2″	1/2″	1/2″
Platen Top	1/2″	1/2″	1/2″	1/2″
Compactor Side Walls	1/2″	1/2″	1/2″	1/2″
Compactor Floor	1/2″	1/2″	1/2″	1/2″

If you need to upgrade your productivity with a Precrush compactor, click below!
