TRANSFER COMPACTORS

Ace Equipment Company transfer compactor

Ace Equipment Company 6-yard and 12-yard stationary compactors are BUILT TUFF / BUILT RIGHT to handle the demands of any transfer station or large industrial application. These compactors are generally mounted on a stand to compact waste directly into transfer trailers. With the capability of processing up to 90 tons of waste per hour, an Ace Equipment Company Transfer Compactor is perfect for your high-volume application.

Perfect for:

  • Transfer Stations
  • Equipment Manufacturers
  • Large Distribution Centers
  • Appliance Manufacturers
REQUEST A QUOTE
DOWNLOAD BROCHURE

FEATURES

  • No Limit Switches
  • Slot & Tab Construction
  • Tongue & Groove Floor
  • 1-1/8” Plate Steel Floor
  • 1’ x 7” Flat Bar Supports
  • AR500 Liners
  • PLC Driven for Improved Productivity
  • Throughput Capacity from 335 yards to
    over 2,000 yards per hour

BENEFITS

  • Replaceable AR500 Liners for Extended Durability and Productivity STANDARD
  • Customizable Loading Chutes Can Be Installed to Allow for Automated Loading of Large Bulk Items to Ensure both Safety and Productivity
  • Our Exclusive Tongue & Groove Floor
    Construction Prevents Debris from Getting
    Underneath the Floor for Smoother
    Operation and Longer Life
  • Our Compaction Cylinders Feature a Bypass Orifice that Provides for a 2-Sec Hold to Allow the Packer to Bleed Off Pressure While at the
    End of the Stroke to Reduce Memory

SPECIFICATIONS AND DIMENSIONS

DIMENSIONA4-TA4-TDPA5-TA6-TA12-TA12-TXHD
A191-1/4″210-3/4″228-3/4″243-1/4″313″344-1/2″
B101-1/2″101-1/2″101-1/2″101-1/2″101-1/2″101-1/2″
C66-1/8″65-1/8″66-1/8″71-3/8″71-3/8″71-3/8″
D48″48″48″50″50″50″
E80-1/2″80-1/2″80-1/2″80-1/2″80-1/2″80-1/2″
F6″6″6″6″6″6″
G52-1/8″52-1/8″52-1/8″53-5/8″53-5/8″53-5/8″
SPECSA4-TA4-TDPA5-TA6-TA12-TA12-TXHD
Clear Top (L x W)63-1/2″ x 80-1/2″65-3/4″ x 80-1/2″82-1/2″ x 80-1/2″87-1/4″ x 80-1/2″122″ x 80-1/2″122″ x 80-1/2″
Capacity4 cubic yard4 cubic yard5 cubic yard6 cubic yard12 cubic yard12 cubic yard
Ram Face Size32-1/8″ x 78-1/8″32-1/8″ x 78-1/8″32-1/8″ x 78-1/8″32-1/8″ x 78-1/8″32-1/8″ x 78-1/8″32-1/8″ x 78-1/8″
Weight14,000 lbs.14,000 lbs.19,000 lbs.27,000 lbs.33,000 lbs.39,500 lbs.
Cycle Time43 sec52sec53 sec58 sec46 sec21sec
Max Normal Force192,422 lbs.141,372 lbs.192,422 lbs.192,422 lbs.192,422 lbs.192,422 lbs.
Max Ram Face Pressure76 psi56 psi76 psi76 psi76 psi76 psi
Ram Penetration28″48″29-1/2″33-1/2″32-1/2″48″
Snout Length25″47″30″32″32″36″
Electric Motor30hp30hp30hp30hp30hp30hp
Control Voltage120 vac120 vac120 vac120 vac120 vac120 vac
Pump Capacity60 gpm60 gpm60 gpm60 gpm60 gpm60 gpm
Max Hydraulic Pressure2,500 psi2,500 psi2,500 psi2,500 psi2,500 psi2,500 psi
Cylinder Count222222
Bore7″6″7″7″7″7″
Rod5″4″5″5″5″5″
Stroke86″107″107″116″150″170″
Face Plate3/4″3/4″3/4″1-1/4″1-1/4″1-1/4″
Platen Sides3/4″3/4″3/4″3/4″3/4″1″
Platen Bottom1″1″1″1″1″1″
Platen Top1/2″1/2″1/2″3/4″3/4″3/4″
Compactor Sidewalls3/4″3/4″3/4″3/4″3/4″1″
Compactor Floor3/4″3/4″3/4″1″1″1-1/4″
